Ncomputing M300

Rs. 17,500.00 Taxes Extra

Up to 45 users per host – Fewer PCs to manage equals lower computing costs per user.
Ethernet Connect - Classrooms, labs or offices can connect at greater distances through the local LAN.
Numo 2 SoC – Provides PC-quality full screen video streaming.
USB Support – Each device includes one USB 2.0 for peripheral support and two USB ports for mouse and keyboard.
vSpace Server Software – Simple to install, easy to configure, no complicated hypervisors to manage and no expensive annual licenses to buy.
vSpace Management Console – Client devices are easily configured through a remote console

SKU: M300. Category: N-Computing Virtualization.

Description
Reviews (0)

Product Description

Ncomputing M300

M-series for vSpace

Overview

Each M300 kit includes 3 client devices*
Share one PC with up to 45 users
Ethernet Connected
Powered by Numo
USB keyboard and mouse
USB 2.0 peripheral support
Microphone & audio out
Energy-efficient (typically 2 watts per user)
Slash PC hardware and support costs by up to 75%
Powerful vSpace® Server desktop virtualization software included
Easy to set up, maintain, manage and secure
Compact and reliable (no fans or disks)
Remote management software included

Hardware
Kit contents	M300 Kit includes three M300 client devices, power supply with power cord, vSpace Server software installation CD/license and User’s guide, Quick Install Guide and VESA screws *
Size	Primary client 160mm(w) x 120mm(d )x 35mm(h) Satellite client: 120mm(w) x 99mm(d) x 33mm(h)
Weight	M300 primary client device: 0.21 kg / 0.46 lbs M300 satellite client device: 0.12 kg / 0.26 lbs
Kit Shipping Weight	0.96 kg or 2.1 lbs ( (includes 3 client devices, power adapter, documentation, etc.)
Power supply	Input: 100-240 VAC, 50-60 Hz Output: 12 VDC, 1.5 A Nominal power consumption: ~6 W (without peripheral USB devices)
Front LED indicators	Primary client: Power: connection to power supply LAN: connection to network green, blinks with traffic Satellite client: Good connection to primary client
Connection to Host	10/100 Mb/s switched Ethernet (1 Gb connection to host recommended)
Connection between primary and satellite clients	Add Cat 5/6 STP cable up to 5 meters between the primary client and the two satellite clients. If USB 2.0 support is desired on the satellite client add USB A/B cables
Video Resolution	From 800×600 to 1440×900 up to 24-bit color support
Audio	Stereo output via speaker port
Microphone	Microphone audio input via port
USB Mouse & Keyboard	Stacked USB ports support Mouse and Keyboard devices (HID devices)
USB 2.0	USB 2.0 port for peripheral support (USB port on the front of device. Must add USB A/B cables to enable support)
Internal HW	Numo2 System-on-Chip with SDRAM and flash Solid-state design, no moving parts, no fans, no local user storage Embedded NComputing firmware (no local user OS)
Reliability	Reliability (MTBF) >250,000 hours (calculated using Bellcore Issue 6 TR-332, Case 2, Part I at 40°C)
Certifications	FCC Class B, CE, KCC and RoHS compliant
vSpace User Support	Maximum number of users per host PC is 45

Software
* Cables Not Included: Requires two CAT5e cables and two USB A/B cables and an Ethernet connection. Host PC, monitor, keyboard, mouse, speakers, cables and other peripherals are NOT included and must be purchased separately. * Application software, client access and OS licenses for the shared PC and M300 may be required by the respective software vendor and must be purchased separately. **** Please refer to the Microsoft operating system licensing requirements and technical details at ncomputing.com/mslicensing. Specific Linux support information is available at ncomputing.com/kb.
Supported Operating Systems****	Microsoft Windows and Ubuntu Linux Refer to the support section at ncomputing.com/support for the latest supported versions
PC Host Requirements	See recommended hardware configuration guide atncomputing.com/support
